Belt Conveyors
INTRODUCTION:
The Star Trace Belt Conveyor is used for transferring material in bulk or container. The belt conveyor is widely used in the industry of mining, building materials, metallurgy, coal and so on. Users can not only transport material with one conveyor or several conveyors, but also can transport with a horizontal/slope transfer system that made up by this kind of conveyors and other conveyors so that can meet the request of different working conditions. It can transport materials in large quantity. It is simple in operation, convenient in maintenance, superior quality.
WORKING PRINCIPLE:
Belt conveyor is a kind of machine that to transfer the material continuously. The belt works under the effect of frictional force. When the materials fall down on the conveyor, the roller under the belt will drive the belt forward. In this way, it conveys the material.
CLASSIFICATION:
Conveyor can be horizontal, tilt and vertical transmission, but also the composition of space transmission lines, transmission lines are generally fixed. Conveyor transport capacity, long-distance, but also in the transportation process while completing a number of process operation, it is widely used. Main belt conveyor, plate conveyor, scraper conveyor, bucket conveyor, bucket elevator, overhead conveyors and so on.
APPLICATION:
- Iron ore & gold
- Coal & fly ash
- Aggregates
- Sand & gravel
- Pulp & paper
- Agricultural
- Chemical
- Food processing
- Process plant & allied industries
FEATURES OF TROUGH BELT CONVEYOR:
- 450mm to 1200mm belt widths
- Modular sturdy-channel section design
- 20, 35 or 45 degree trough angle frames
- Spillage reduction features & skirts
- Conveyor-belt-cleaner / Primary cleaner
- Drive roller rubber lagged, crowned end pulleys
- Belt speed optioned to suite load capacity
- Medium or Heavy duty belt-idler-pulleys, bearings and components
Technical Specification for Belt Conveyor:
Further Reference to the above, below Specification Is for Sample Only.
Our Product Is Customized One It Will Change as per Customers Requirement
- Make : Star Trace
- Equipment : Belt Conveyor
- Belt Width : 500 Mm
- Conveyor Length : 10675 Mm
- Profile : Horizontal
- Belt Type : 3 Ply×315/3×3mm+1.5mm
- Belt Speed : 70m/min
- Drive : 3.5 Kw, 3 Phase, 415 V, 50 Hz
- Motor Make : Abb/crompton/transteck
- Gear Box Make : Bonfiglioli/ Primimum Greaves/ Transteck
- Drive Coupling : Direct Mounted
